3D CAD Modelling

Checking draft angles is important prior to ordering injection mould tooling

From very large & complex items to small individual items it is possible to model your existing products or components in 3D CAD using SolidWorks Professional. Everything from industrial switchgear to PCB components. Some examples can be found on GrabCAD.com

Get in touch if you have a similar project.
