Raw 3D scan data for a fresnel lens prior to import into SolidWorks
The off-tool injection molded fresnel lens component for an LED COB light source
Scan data was cleaned up prior to using the profile to create the final CAD model on SolidWorks
Using SolidWorks it is possible to import 3D scan data and make a replica CAD part or make changes to the geometry.
